TE Connectivity
Typical Performance Characteristics
Number of Poles : 1 to 4
Switch Functions : ON-ON, ON-(ON), ON-OFF-ON, ON-ON-ON,
ON-OFF-(ON), (ON)-OFF-(ON)
Contact Rating : 6 A @250 VAC, 6 A @125 VAC,
Gold Contact : 0.4 VA max. 20 V AC/DC
electrical Life : 25,000 to 50,000 cycles
Mechanical Life : 50,000 to 100,000 cycles
Contact Resistance : Max. 10 mOhm
0.4 VA Max. at 2–4 VDC 100 mA
125/250 VAC at 2–4 VDC 1 A
insulation Resistance : Min. 1,000 MOhm
Dielectric Strength : 1,000 VAC for 1 min.
Actuation Force : Max. 19.6 N
Panel Cut-out : 6.2 mm
Standards and Specs : UL, CSA
environmental Specification
operating Temperature : -20 to +70°C
Storage Temperature : -20 to +70°C
Vibration Resistance : 1.5 mm 10-55 Hz
Shock Resistance : 50 g for 11 ± 1 msec
Terminal Strength : 24.5 N
F Series Toggle Switches Product key
F Series Switches
Material Specifications
Contacts : Brass silver alloy finish
Toggle : Brass chromium plated
Terminals : Brass plate
Case : Phenol resin
Cover : Steel zinc plated
Seal : Rubber seal, insert molded rubber
other Characteristics
Contact Timing : Break before Make
Right Angle Versions : No
Standard Number of Positions : 2 or 3
Terminals / Mounting Style : Leadwire hooking
Actuator Style : Standard, long locking; rocker
Dimensions Case (LxWxH) : 14.8 x 8 ... 23 x 10.5 mm
Packaging : Bulk
Choice of momentary or maintained circuits
Type
Typical Product Key
F
T
D
0
9
04
F
F Series power toggle switch
Number of Poles
Blank 1 & 2 pole
Model
T
Toggle
Switch Function & Poles
1 & 3 pole
3
4
3 poles
4 poles
2 & 4 pole
D
E
F
G
H
ON-ON
ON-OFF-ON
ON-(ON)
(ON)-OFF-(ON)
ON-OFF-(ON)
N
P
R
S
T
PA
ON-ON
ON-OFF-ON
ON-(ON)
(ON)-OFF-(ON)
ON-OFF-(ON)
ON-ON-ON
Actuator
0
5
Standard toggle
Locking lever
7
Long flat toggle
Terminal Type
9
Leadwire hooking type
Contact Material
Blank Silver
Material
04
RoHS Compliant
te.com/products/switches
G
Gold
